How this site is actually put together

The only flow a visitor causes. Nothing is fetched from the browser: the server component asks the repository port, the answer becomes HTML, and what arrives is already finished.

• GET /api/v1/profile
• GET /api/v1/jobs
• GET /api/v1/projects
• GET /api/v1/nodes
• GET /api/v1/skills/categories
• GET /api/v1/schema/erd
• GET /api/v1/trace/snapshot

1. 1
   Browser

   Asks for a route. This is the last thing the browser does on the read path — there is no client fetch behind it.

   GET /
2. 2
   Next.js server

   The route's server component reads everything it needs in one Promise.all, through the port rather than the API.

   cvRepository.listJobs()
3. 3
   @cv/data

   HttpCvRepository is the only module that knows the API's origin. It calls the typed client generated from the OpenAPI schema, and attaches Next's revalidation window here.

   next: { revalidate: 60 }
4. 4
   FastAPI

   A read route, so no token is asked for. The handler is a lookup and a response model; the service beneath it has done the work.

   GET /api/v1/jobs
5. 5
   Service → repository

   The service composes, the repository holds the SQLAlchemy query. The trace snapshot is the one that earns the split: it resolves the whole graph in a single pass rather than in 36 round trips.

6. 6
   PostgreSQL → the page

   Rows come back, Pydantic serialises them, the adapter narrows tone and status into domain types, and the section renders on the server. The trace snapshot is dehydrated into the client cache so the one client island starts warm.

The editor's create path. The browser never learns the API's address or its token: it posts to a proxy on this origin, and the proxy is where the credential is attached.

• POST /api/v1/jobs
• POST /api/v1/projects
• POST /api/v1/nodes
• POST /api/v1/skills
• POST /api/v1/skills/categories

1. 1
   Admin editor

   The form posts to this origin. Same-origin, so no CORS — and no credential within reach of any script the page loads.

   POST /api/admin/jobs
2. 2
   Next route handler

   A catch-all that validates rather than forwards: the resource name must be one of five, and every segment is checked against a character class, so nothing can walk out of the namespace.

   parseTarget(segments)
3. 3
   Next route handler

   Reads the httpOnly session cookie. That token has never been readable by a script on the page, which is the whole reason this hop exists.

   readAdminToken()
4. 4
   @cv/data

   The write port is built from that token per request, not once from the environment — a module-level singleton would mean one process-wide credential shared by everyone who opens the editor.

   repository.create(resource, body)
5. 5
   FastAPI

   The write gate compares the bearer token in constant time. No token configured answers 503, a wrong one answers 401 — an operator problem and a caller problem are not the same thing.

6. 6
   Service → PostgreSQL

   Pydantic validates the shape; the service refuses a payload naming a skill that does not exist, then commits the row, its bullets and its skill relations as one unit of work.

   422 · Unknown skill(s) in uses: COBOL

The same door as a create, with one difference that matters: the payload is partial. A field that is not sent is left alone rather than nulled, so editing a role's dates cannot silently erase its bullets.

• PATCH /api/v1/profile
• PATCH /api/v1/jobs/{id}
• PATCH /api/v1/projects/{id}
• PATCH /api/v1/nodes/{id}
• PATCH /api/v1/skills/{id}
• PATCH /api/v1/skills/categories/{id}

1. 1
   Admin editor

   The form sends only the fields the editor changed.

   PATCH /api/admin/jobs/{id}
2. 2
   Next route handler

   The profile is the one row addressed without an id — it is a single row, so it has no create and no delete — and it is matched before the id check every other resource goes through.

3. 3
   @cv/data

   The same per-request write port and the same bearer token, with a different verb.

   repository.update(resource, id, body)
4. 4
   FastAPI

   The write gate again, then the row is loaded — or the request 404s before anything has been changed.

   self.jobs.require(job_id)
5. 5
   Service

   Only the fields actually supplied are copied across. Lists are the exception: bullets and skill relations are replaced wholesale, because merging an ordered list by index would quietly reorder it.

   payload.model_dump(exclude_unset=True)
6. 6
   PostgreSQL

   One commit. A role plus its bullets plus its two sets of skill rows either all land or none of them do.

The shortest flow, and the one with the widest blast radius, because the join tables cascade. Deleting a skill removes it from every role, project and architecture card that referenced it.

• DELETE /api/v1/jobs/{id}
• DELETE /api/v1/projects/{id}
• DELETE /api/v1/nodes/{id}
• DELETE /api/v1/skills/{id}
• DELETE /api/v1/skills/categories/{id}

1. 1
   Admin editor

   No body to send, so there is nothing to validate on the way in.

   DELETE /api/admin/jobs/{id}
2. 2
   Next route handler

   An id is required here: the same handler refuses a delete addressed at a collection, which is the one mistake in this shape of API that cannot be undone.

3. 3
   @cv/data

   A 204 carries no body, so the write port returns undefined rather than trying to parse one, and the proxy answers 204 in turn.

   repository.remove(resource, id)
4. 4
   FastAPI

   Gated like every other write, then loaded — deleting something that was already gone is a 404, not a quiet success.

5. 5
   Service → PostgreSQL

   The row goes, and ON DELETE CASCADE takes the join rows with it. A category is the exception: it is refused while it still holds skills, because taking a category out from under them would delete work nobody asked to delete.

6. 6
   The page

   Nothing else has to be told. The trace graph, the skill rail and the ERD are all derived from rows, so they are correct on the next revalidation without a line changing.
